Home > Cold Storage Panels >

Insulated Cold Storage Wall Panels / Cold Room Control Panel High Density

Product Categories

ECOOL INTERNATIONAL TRADING (Shanghai) Co., Ltd.

Contact Now

Name: Insulated Cold Storage Wall Panels Cold Room Control Panel High Density
Brand: Ecool
Price: 1 USD

Brand Name : Ecool

Model Number : EP012

Certification : ISO9001,CCC,

Place of Origin : China

MOQ : Negotiation

Price : Negotiable

Supply Ability : 15000000 square meter/year

Delivery Time : 3-4 Working weeks

Packaging Details : Standard Export Package

Name : Cold Storage Wall Panels

Warranty : 1Year

Package : films on both size

Foam density : 40Kg/M3

Firefighting level : B2

Feature : Insulated

Contact Now

Insulated Cold Storage Wall Panels / Cold Room Control Panel High Density

Cold Storage Wall Panels Features

It uses advanced equipment for foaming, uniform foam quality, and the bulk density is generally 40±2kg/m3.
Polyurethane foaming, environmental protection, anti-corrosion, flame retardant (self-extinguishing within 3 seconds - 5 seconds), anti-moisture, good insulation performance.
Multiple Choices:Length--- Match the actual data and choose within 16 meters;Surface---Color steel, stainless steel, galanvanized steel, without steel; Core thickness---50mm to 250mm
Good thermal performance, strong resistance to deformation, not easy to crack, stable and safe finish.

Cold Storage Wall Panels Performance data

No	Item		Unit	Tech requirement
1	density		Kg/㎡	40±2
2	Heat conductivity		W/m.k	≤ 0.024
3	Compressive strength		Kpa	≥150
4	Combustion performance		--	B2 grade
5	The bond strength between sandwich core layer and panel		Mpa	>0.1
6	Stripping performance	The core material on the surface	--	Uniform distribution
6	Stripping performance	The adhesive area of each stripping surface	--	≥90%

Cold Storage Wall Panels details

Name	Cold Storage Wall Panels
Protective surface Material	Color steel sheet,stainless steel sheet,or other.
Place of Origin	China
Length	Max. 16m
Effective Width	1120mm
Core thickness	50mm,75mm,100mm,120mm,150mm,180mm,200mm,250mm
Features	Soundproof, fireproof, waterproof
Certificates	SGS, ISO14001, ISO9001,
Color	Whit grey
Lifetime	10-30 years
Fire proof rate	B1,B2
Usage	In different fields: Food storage, Lab center, Medicine factory,Logistics Center, Cold Drinks Processing Center …ect

Why choose us

1. Top 3 panel factory in China

2. Automatic production line produce 3000 sqm per day

3. Provide drawing, installation instruction
